Home / Remanufactured / Pressure transmitters / Rosemount 3051CD
Shown: Rosemount 3051Rosemount® 3051CD SMART® transmitter
The 3051CD is a differential pressure transmitter. Our remanufacturing partner builds it to your model number: same output, range, wetted parts and mounting.
The full model string off the nameplate, for example 3051CD2A22A1AB4M5, is a complete request. A photo of the plate works too.
Specifications
| Measurement | Differential pressure · gauge · liquid level · flow |
|---|---|
| Output | 4–20 mA with HART® digital signal · low-power 1–5 V dc · low-power 0.8–3.2 V dc (optional) |
| Range | 0–0.1 in H₂O up to 0–2000 psid |
| Accuracy | ±0.04% to ±0.10% of span, range-dependent |
| Power | 10.5–42.4 V dc (4–20 mA) · 6–12 V dc (low power), no load |
| Wetted parts | SST, Hastelloy, Monel, Tantalum |
| Fill fluid | Silicone · inert (halocarbon) |
| Mounting | Coplanar and traditional flanges · adapters in Cd/Ni-plated CS or 316 SST |
Not every configuration is available on every model. The quote confirms yours.
How the quote works
- Send the nameplate: the full model number for instruments, or process conditions for valves
- One written quote: price and lead time, with the options side by side
- One contact: you deal with us from quote to delivery
Related remanufactured equipment
Rosemount® and SMART® are trademarks of Rosemount Inc. / Emerson. Remanufactured transmitters are built by our remanufacturing partner, not by Emerson or Rosemount and not with their endorsement. DWP Industrial Sales is your supplier, and you deal with us from quote to delivery. Remanufactured equipment is not FM/CSA approved for hazardous locations.
